Increase the thermal control and acoustic performance by partnering with our Engineers to see which film and facing works best for you. Since 1980 we’ve been providing different films and facing for different applicants across an array of markets.
Let Us Help On Your Next Project!
Protective Films & Radiant Heat Barriers
Impervious barrier films engineered to prevent oil, diesel, hydraulic fluid, and moisture ingress while reflecting radiant engine heat.
| Code | Material Construction | Key Performance Properties | Primary OEM Applications |
|---|---|---|---|
| -AP | Metalized PET Film (Aluminized Polyester) | Reflects radiant heat; moisture and fluid barrier; lightweight, smooth cleanable surface | Engine enclosures, generator canopies, HVAC ductwork |
| -AR | Reinforced Aluminized Polyester Film | High tensile and tear strength; radiant heat reflection; puncture-resistant scrim reinforcement | Heavy-duty construction cabs, off-highway engine bays |
| -RA / -FF | Reinforced Aluminum Foil Facing | Maximum radiant heat reflection; rugged tear resistance; blocks oil, fuel, and vapor | High-heat exhaust compartments, power generation enclosures |
| -UB | 2-mil Black Urethane Film | Superior abrasion, puncture, and chemical resistance; highly flexible over contoured foam | Fluid pumps, air compressors, high-wear industrial housings |
| -CL | Clear PET (Polyester) Film | Moisture and fluid barrier without altering substrate appearance; chemical resistance | Medical devices, cleanroom enclosures, industrial machinery |
| -WR | White Reinforced PET Film | Bright, light-reflective finish; tear-resistant reinforcement; wipe-clean moisture barrier | Interior equipment panels, marine engine rooms, utility vehicles |
Acoustically Transparent & Heavy-Duty Facings
Perforated vinyls, non-woven fabrics, and fiberglass cloths designed to maximize Noise Reduction Coefficient (NRC) ratings or withstand extreme abrasion.
| Code | Facing Type | Acoustic & Physical Attributes | Primary OEM Applications |
|---|---|---|---|
| -NW / -NR | High-NRC Non-Woven Facing (White / Black) | Acoustically transparent; prevents fiber shedding; preserves peak sound absorption across mid-to-high frequencies | Generator enclosures, compressor housings, HVAC equipment |
| -FS | Flame Shield Fire-Resistant Scrim | Flame-retardant reinforcement; dimensional stability; allows sound waves to pass into absorber core | Mass transit, commercial vehicles, UL-regulated enclosures |
| -PB / -PC | Black Perforated Vinyl (14% Open Area / Crushed) | 14% open area balances acoustic transparency with durable, wipe-clean aesthetics | Heavy truck cabs, agricultural tractor interiors, marine cabins |
| -PG | Gray Perforated Vinyl (18% Open Area) | Increased 18% open area for higher mid-frequency sound absorption; rugged vinyl finish | Operator cab headliners, industrial control rooms, bus interiors |
| -FA / -FB | Vinyl-Impregnated Fiberglass Cloth (Gray / Black) | Extreme tear, flame, and abrasion resistance; heavy-duty industrial durability | Mining machinery, heavy-duty power units, harsh industrial plants |
| -DF / -DT / -GT / -LT | Textured Embossed Vinyls (Diamond Plate, Deep Twist, Lava Twist) | Scuff-resistant cosmetic finishes in Black or Gray; hides wear and minor surface imperfections | Cab floor mats, kick panels, visible equipment trim |
Industrial Pressure-Sensitive Adhesives (PSAs)
High-performance transfer and scrim-supported adhesives engineered for reliable OEM assembly across metals, plastics, and flexible barriers.
| Code | Adhesive Chemistry & Thickness | Bonding Characteristics | Recommended Substrates |
|---|---|---|---|
| -32 / -92 | 2-mil Acrylic PSA | High shear strength; strong resistance to UV, heat, and aging; thin bond line | Smooth painted metals, stainless steel, aluminum, rigid plastics |
| -33 / -93 / -97 / -98 | 3-mil Acrylic PSA (Standard & Scrim-Supported) | Higher coat weight for slightly textured surfaces; scrim option (-33) prevents stretching during installation | Powder-coated enclosures, stamped metal panels, textured housings |
| -34 / -94 | 4-mil High-Coat-Weight Acrylic PSA | Maximum wet-out on rough, embossed, or uneven substrates; superior long-term holding power | Castings, rough fiberglass, heavily textured powder coats |
| -99 | 3-mil Low Surface Energy (LSE) Acrylic PSA | High initial tack and peel strength specifically formulated to wet out hard-to-bond plastics | Polypropylene (PP), polyethylene (HDPE/LDPE), TPO, oily metals |
| -57 | Plasticizer-Resistant Acrylic PSA | Prevents adhesive softening and bond failure caused by plasticizer migration over time | Flexible PVC, vinyl barriers, Mass Loaded Vinyl (MLV) |
| -91 | 3-mil Synthetic Rubber PSA | Aggressive, instant grab (quick-stick) at room temperature; cost-effective assembly | Low-to-medium temperature interior panels, general OEM assembly |
Ready to Get Started?
Talk to an ExpertFrequently Asked Questions: Films, Facings & Adhesives
How do protective films affect the acoustic absorption of foam or polyfiber?
Solid barrier films (such as aluminized PET or urethane) reflect high-frequency sound waves while shifting absorption toward lower frequencies via diaphragmatic action. When maximum mid-to-high frequency sound absorption (NRC) is required, Technicon Acoustics recommends acoustically transparent non-woven facings (-NW/-NR) or perforated vinyls (-PB/-PC/-PG) with 14% to 18% open area.
Which facing prevents oil, diesel, and moisture absorption in engine bays?
Impervious films including Metalized PET (-AP), Reinforced Aluminized Polyester (-AR), Reinforced Aluminum Foil (-RA/-FF), and 2-mil Black Urethane (-UB) completely seal open-cell acoustic foams against oil, fuel, hydraulic fluid, and water ingress. Combining these films with Technicon’s edge-sealing process maximizes part lifespan in harsh engine environments.
Which PSA adhesive should I specify for powder-coated metal vs. polypropylene plastics?
For smooth or lightly textured powder-coated metals, 3-mil or 4-mil high-coat-weight acrylic PSAs (-33, -93, -94) provide high shear and heat resistance. For Low Surface Energy (LSE) plastics such as polypropylene (PP), polyethylene (HDPE), or TPO, specify our -99 3-mil LSE Acrylic PSA for reliable initial tack and permanent bond strength.
Why is a plasticizer-resistant adhesive (-57) needed for Mass Loaded Vinyl (MLV)?
Flexible PVC and Mass Loaded Vinyl contain plasticizers that naturally migrate to the surface over time, softening standard adhesives and causing parts to peel off. Technicon’s -57 Plasticizer-Resistant Acrylic PSA is formulated to block plasticizer migration and maintain bond integrity on MLV and vinyl substrates.
Can Technicon Acoustics laminate multi-layer composites with custom die-cut shapes?
Yes. All thermal lamination, flame lamination, adhesive backing application, and CNC knife/waterjet die-cutting are performed in-house at our ISO 9001:2015 certified Concord, NC facility. We supply custom-engineered multi-layer acoustic and thermal kits ready for direct OEM assembly line installation.
What are Technicon Acoustics’ standard lead times and prototyping capabilities?
Our standard production lead time is two weeks, with expedited fulfillment available for time-critical OEM schedules. Our in-house engineering team and acoustic lab also support rapid prototyping, material selection testing, and custom composite configurations across more than 3,000 proven material combinations.
